| Properties | Test Method | Test Condition | Unit | Typical Value |
| Physical |
|
|
|
|
| Specific Gravity , 23oC |
| ASTM D792 | - | 1.04 |
| Mold Shrinkage , 3.2mm |
| ASTM D955 | % | 0.4 ~ 0.7 |
| Melt Flow Rate | 220oC, 10kg | ASTM D1238 | g/10min | 43 |
| Mechanical |
|
|
|
|
| Tensile Strength 3.2mm @Yield | 50mm/min | ASTM D638 | kg/cm2 | 423 |
| Tensile Elongation 3.2mm @ Break | 50mm/min | ASTM D638 | % | 36 |
| Flexural Strength , 6.4mm | 10mm/min | ASTM D790 | kg/cm2 | 585 |
| Flexural Strength , 6.4mm | 10mm/min | ASTM D790 | kg/cm2 | 20,153 |
| Izod Impact Strength , Notched, 6.4mm | 23oC | ASTM D256 | kg*cm/cm | 28 |
| Rockwell Hardness | R-Scale | ASTM D785 | - | 106 |
| Thermal |
|
|
|
|
| HDT ,6.4mm(Unannealed),6.4mm | 18.6kg | ASTM D648 | oC | 82 |
| Flammability |
| UL 94 |
| HB |
| Relative Temperature Index |
| UL 746B |
|
|
| Electrical |
|
| oC | 60 |
| Mechanical with Impact |
|
| oC | 60 |
| Mechanical without Impact |
|
| oC | 60 |
| Electrical |
|
|
|
|
| Comparature Tracting Index(CTI) | Solution A | IEC 60112 | Volts | 1 |
| Surface Resistivity |
| IEC 60093 | Ohm |
|
| Volume Resistivity | 23oC | ASTM D257 | Ohm.m |
|
| Arc Resistivity | 23oC | ASTM D495 | Ohm.cm | 6 |
